Mitsubishi eK Active 2004–2006

1 generation (H81W)

General information

Number of doors5

Car classB

CountryJapan

Steering wheel positionRight

At a glance

Engine657 cm3 Gasoline

Power50 hp

GearboxAutomatic

Origin

Japan

Trim

0.7 (64 PS)0.7 AT 4WD (50 hp)

Specifications

Engine

Compression ratio10.2

Number of cylinders3

Max power (kW)37 kW

Engine code3G83 DOHC i

Valves per cylinder4

Turnover of maximum torque4000 RPM

Engine power50 hp

Engine power50 PS

Maximum torque62 N*m

Cylinder bore65 mm

Max power at RPM6500 RPM

Capacity657 cm3

Stroke cycle66 mm

Injection typedistributed injection (multipoint)

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Timing beltSOHC

Bodywork

Front track width1295 mm

Back track width1295 mm

Width1475 mm

Height1600 mm

Clearance165 mm

Wheelbase2340 mm

Length3395 mm

Number of seater4

Curb weight840 kg

Body typeMinibus

Gearbox and handling

Number of gear4

Gearbox typeAutomatic

Drive wheelsFront wheel drive

Operating characteristics

Max speed134 km/h

Acceleration (0-100 km/h)21.2 s

Fuel tank capacity30 l

Highway driving fuel consumption per 100 km5.2 l

Mixed driving fuel consumption per 100 km6.2 l

City driving fuel consumption per 100 km7.6 l

Fuel95

Suspension and brakes

Rear brakesdrum

Front suspensionIndependent, spring

Back suspensionSemi-dependent, spring

Front brakesventilated disc
