Mitsubishi Grandis 2003–2005

1 generation (NA4W / NA8W)

At a glance

Engine1968 cm3 Diesel

Power134 hp

GearboxManual

OriginN/A

Trim

2.0 DI-D MT (134 hp)2.0 MT (136 PS)2.4 AT (162 hp)2.4 AT 4WD (165 PS)2.4 MT (162 hp)2.4 MT (165 PS)2.4 MT 4WD (165 PS)

Specifications

Engine

Max power (kW)100 kW

Engine power134 hp

Engine power136 PS

Capacity1968 cm3

Maximum torque310 N*m

Number of cylinders4

Valves per cylinder4

Cylinder bore81 mm

Stroke cycle96.5 mm

Engine typeDiesel

Injection typedirect injection

Cylinder layoutInline

Presence of intercoolerPresent

Turnover of maximum torqueto 1 750 RPM

Max power at RPMto 4 000 RPM

Boost typeTurbo

Bodywork

Max trunk capacity1545 l

Ground clearance155 mm

Front track1550 mm

Rear track1555 mm

Height1670 mm

Curb weight1710 kg

Width1795 mm

Full weight2335 kg

Wheelbase2830 mm

Min trunk capacity320 l

Trailer load (with brakes)4335 kg

Length4765 mm

Payload625 kg

Number of seater7

Body typeMinivan

Gearbox and handling

Turning circle11.6 m

Number of gear6

Drive wheelsFront wheel drive

Gearbox typeManual

Operating characteristics

Acceleration (0-100 km/h)10.8 s

Max speed195 km/h

Highway driving fuel consumption per 100 km5.6 l

Fuel tank capacity65 l

Mixed driving fuel consumption per 100 km6.6 l

City driving fuel consumption per 100 km8.4 l

Fueldiesel

Emission standardsEURO IV

Cruising rangefrom 770 to 1 160 km

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, McPherson Struts, spring, Stabilizer bar

Back suspensionIndependent, Trailing arms, spring, Stabilizer bar

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.

No grades recorded for this trim yet.
