Mitsubishi Carisma 1999–2004

1 generation [restyling] (DA)
General information
Number of doors4
Car classD
CountryJapan
Steering wheel positionLeft/Right
At a glance
Engine1298 cm3 Gasoline
Power80 hp
GearboxManual
OriginJapan
Series
Hatchback 5 doorsLiftbackSedan
Trim
1.3 MT (82 PS)1.6 AT (103 PS)1.6 AT (90 PS)1.6 AT (99 PS)1.6 MT (103 PS)1.6 MT (90 PS)1.6 MT (99 PS)1.8 AT (125 PS)1.8 GDI AT (122 PS)1.8 GDI MT (122 PS)1.8 MT (125 PS)1.9 DI-D MT (115 hp)1.9 TD MT (102 PS)

Specifications

Engine
Compression ratio10
Maximum torque120 N*m
Capacity1298 cm3
Number of cylinders4
Valves per cylinder4
Turnover of maximum torque4000 RPM
Engine code4G13
Max power at RPM5000 RPM
Max power (kW)60 kW
Cylinder bore71 mm
Engine power80 hp
Stroke cycle82 mm
Engine power82 PS
Injection typedistributed injection (multipoint)
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Timing beltOHC
Bodywork
Curb weight1170 kg
Ground clearance140 mm
Height1405 mm
Rear track1470 mm
Back track width1470 mm
Front track1475 mm
Front track width1475 mm
Clearance150 mm
Full weight1675 kg
Width1710 mm
Wheel size175/65 R15, 195/60 R15
Wheelbase2550 mm
Length4475 mm
Max trunk capacity460 l
Min trunk capacity480 l
Number of seater5
Pitch Circle DiameterDIA67.1 4x114.3 mm
Body typeSedan
Gearbox and handling
Turning circle11.2 m
Number of gear5
Drive wheelsFront wheel drive
Gearbox typeManual
Operating characteristics
Acceleration (0-100 km/h)14.1 s
Max speed175 km/h
Highway driving fuel consumption per 100 km5.2 l
Fuel tank capacity60 l
Mixed driving fuel consumption per 100 km6.4 l
City driving fuel consumption per 100 km8.4 l
Fuel95
Cruising rangefrom 710 to 1 150 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
