Mercedes-Benz G-Class 1990–2006

2 generation (W463)
General information
Number of doors2
CountryGermany
Car classJ
Steering wheel positionLeft
At a glance
Engine3449 cm3 Diesel
Power134 hp
GearboxAutomatic
OriginGermany
Series
SUV 3 doorsSUV 5 doorsSUV opened
Trim
2.3 AT 4WD (125 PS)2.3 MT 4WD (125 PS)3.0 AT 4WD (113 PS)3.0 AT 4WD (170 PS)3.0 AT 4WD (177 PS)3.0 MT 4WD (113 PS)3.0 MT 4WD (170 PS)3.2 AT 4WD (210 hp)3.2 AT 4WD (215 PS)350 3.5d AT (136 PS) 4WD4.0 AT 4WD (250 PS)5.0 AT 4WD (296 PS)

Specifications

Engine
Max power (kW)100 kW
Engine power134 hp
Engine power136 PS
Turnover of maximum torque1800 RPM
Valves per cylinder2
Compression ratio22
Maximum torque305 N*m
Capacity3449 cm3
Max power at RPM4000 RPM
Number of cylinders6
Cylinder bore89 mm
Stroke cycle92.4 mm
Engine typeDiesel
Engine placementFront, longitudinal
Injection typeHPFP (Diesel)
Cylinder layoutinline
Timing beltOHC
Engine codeOM603.972
Boost typeTurbocharged
Bodywork
Front track width1475 mm
Back track width1475 mm
Max trunk capacity1580 l
Width1760 mm
Height1945 mm
Clearance220 mm
Curb weight2200 kg
Min trunk capacity238 l
Wheelbase2400 mm
Wheel size255/65/R16
Full weight2750 kg
Length4275 mm
Number of seater5
Body typeCrossover
Pitch Circle DiameterDIA84.1 5x130 mm
Gearbox and handling
Number of gear4
Drive wheelsAll wheel drive (AWD)
Gearbox typeAutomatic
Operating characteristics
Mixed driving fuel consumption per 100 km11.6 l
Max speed145 km/h
City driving fuel consumption per 100 km15.2 l
Acceleration (0-100 km/h)17.6 s
Highway driving fuel consumption per 100 km9.3 l
Fuel tank capacity96 l
Fueldiesel
Suspension and brakes
Front suspensionDependent, spring
Rear brakesdrum
Back suspensionIndependent, spring
Front brakesventilated disc
