Mercedes-Benz B-Class 2014–2018

2 generation (W246 / W242) [restyling]

General information

Number of doors5

Car classC

CountryGermany

Steering wheel positionLeft

At a glance

Engine1461 cm3 Diesel

Power107 hp

Gearboxrobot

Origin

Germany

Trim

1.5 AMT (109 PS)1.5 AMT (90 PS)1.5 MT (90 PS)1.6 AMT (102 PS)1.6 AMT (122 PS)1.6 AMT (156 PS)1.6 MT (102 PS)1.6 MT (122 PS)1.6 MT (156 PS)2.0 AMT (156 PS)2.0 AMT 4WD (184 PS)2.0 AMT 4WD (211 PS)2.0 MT (156 PS)2.0 MT (211 PS)2.1 AMT 4WD (136 PS)2.1 AMT 4WD (177 PS)2.1 MT (136 PS)AT (179 PS)

Specifications

Engine

Engine power107 hp

Engine power109 PS

Capacity1461 cm3

Compression ratio15.6

Valves per cylinder2

Turnover of maximum torque2500 RPM

Maximum torque260 N*m

Number of cylinders4

Max power at RPM4000 RPM

Cylinder bore76 mm

Max power (kW)80 kW

Stroke cycle80.5 mm

Injection typeCommon rail (diesel)

Engine typeDiesel

Timing beltDOHC

Engine placementFront, transverse

Cylinder layoutinline

Engine codeOM607.951

Engine modelom 607 de 15 la

Boost typeTurbocharged

Bodywork

Clearance125 mm

Curb weight1450 kg

Max trunk capacity1547 l

Back track width1549 mm

Front track width1552 mm

Height1557 mm

Width1786 mm

Wheel size195/55 R16, 205/55 R16

Full weight1985 kg

Wheelbase2699 mm

Length4393 mm

Min trunk capacity488 l

Number of seater5

Disc size6.5x15 ET47, 6.5x16 ET49, 6.5x17 ET49, 7.5x17 ET52.5, 7.5x18 ET52

Pitch Circle DiameterDIA66.6 5x112 mm

Body typeHatchback

Gearbox and handling

Number of gear7

Drive wheelsFront wheel drive

Gearbox typerobot

Operating characteristics

Acceleration (0-100 km/h)11.9 s

Max speed190 km/h

Highway driving fuel consumption per 100 km4.0 l

Mixed driving fuel consumption per 100 km4.2 l

City driving fuel consumption per 100 km4.5 l

Fuel tank capacity50 l

Fueldiesel

Emission standardsEuro 6

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Safety

Safety assessment5 / 5

Rating nameEuroNCAP

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
