Mazda CX-5 2011–2015
1 generation (KE)General information
Number of doors5
Car classC
CountryJapan
Steering wheel positionLeft/Right
At a glance
Engine1997 cm3 Gasoline
Power148 hp
GearboxAutomatic
Origin
Japan
JapanTrim
2.0 AT (150 hp)2.0 AT 4WD (150 PS)2.0 AT 4WD (155 hp)2.0 AT 4WD (160 hp)2.0 MT (150 PS)2.0 MT (155 hp)2.0 MT 4WD (160 hp)2.0 SKYACTIV-G AT (157 hp)2.0 SKYACTIV-G AT AWD (157 hp)2.0 SKYACTIV-G AT AWD (160 hp)2.0 SKYACTIV-G MT (157 hp)2.0 SKYACTIV-G MT (165 hp)2.0 SKYACTIV-G MT AWD (160 hp)2.2 AT 4WD (150 hp)2.2 D AT 4WD (175 PS)2.2 MT 4WD (150 hp)2.2 MT 4WD (175 hp)2.2 SKYACTIV-D AT (150 hp)2.2 SKYACTIV-D AT (175 hp)2.2 SKYACTIV-D AT AWD (150 hp)2.2 SKYACTIV-D AT AWD (175 hp)2.2 SKYACTIV-D MT (150 hp)2.2 SKYACTIV-D MT AWD (150 hp)2.2 SKYACTIV-D MT AWD (175 hp)2.5 AT (184 hp)2.5 AT 4WD (192 PS)2.5 SKYACTIV-G AT (187 hp)2.5 SKYACTIV-G AT AWD (187 hp)
Specifications
Engine
Max power (kW)110 kW
Compression ratio14
Engine power148 hp
Engine power150 PS
Capacity1997 cm3
Maximum torque210 N*m
Number of cylinders4
Valves per cylinder4
Turnover of maximum torque4000 RPM
Max power at RPM6000 RPM
Cylinder bore83.5 mm
Stroke cycle91.2 mm
Injection typedirect injection (direct)
Timing beltDOHC
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Engine modelPE-VPS
Engine codePE-VPS
Bodywork
Front/rear axle load1040/1105 kg
Curb weight1400 kg
Max trunk capacity1560 l
Front track1585 mm
Front track width1585 mm
Rear track1590 mm
Back track width1590 mm
Height1670 mm
Width1840 mm
Full weight2050 kg
Ground clearance215 mm
Clearance215 mm
Wheel size225/55 R19, 225/65 R17
Wheelbase2700 mm
Min trunk capacity403 l
Trailer load (with brakes)4045 kg
Length4555 mm
Number of seater5
Payload595 kg
Body typeCrossover
Pitch Circle DiameterDIA67.1 5x114.3 mm
Gearbox and handling
Turning circle11.7 m
Number of gear6
Drive wheelsAll wheel drive (AWD)
Gearbox typeAutomatic
Operating characteristics
CO2 emissions147 g/km
Max speed187 km/h
Fuel tank capacity58 l
Highway driving fuel consumption per 100 km5.9 l
Mixed driving fuel consumption per 100 km6.7 l
City driving fuel consumption per 100 km8.2 l
Acceleration (0-100 km/h)9.4 s
Fuel95
Emission standardsEuro 4
Cruising rangefrom 710 to 980 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc
