Mazda CX-5 2017–2021

2 generation (KF)
General information
Number of doors5
Car classC
CountryJapan
Steering wheel positionLeft/Right
At a glance
Engine1997 cm3 Gasoline
Power148 hp
GearboxAutomatic
OriginJapan
Trim
2.0 AT (150 PS)2.0 AT (155 PS)2.0 AT (165 hp)2.0 AT 4WD (150 PS)2.0 AT 4WD (160 hp)2.0 AT 4WD (165 hp)2.0 AT AWD (150 PS)2.0 MT (150 PS)2.0 MT (165 hp)2.0 MT 4WD (160 hp)2.2 AT (150 hp)2.2 AT (190 hp)2.2 AT (200 hp)2.2 AT 4WD (150 hp)2.2 AT 4WD (175 hp)2.2 AT 4WD (184 hp)2.2 AT 4WD (190 hp)2.2 AT 4WD (200 hp)2.2d AT AWD (175 hp)2.2 MT (150 hp)2.2 MT (190 hp)2.2 MT (200 hp)2.2 MT 4WD (150 hp)2.2 MT 4WD (184 hp)2.2 MT 4WD (190 hp)2.2 MT 4WD (200 hp)2.5 AT (190 hp)2.5 AT (230 hp)2.5 AT 4WD (194 PS)2.5 AT 4WD (196 PS)2.5 AT 4WD (230 hp)2.5 AT 4WD (254 hp)2.5 AT AWD (194 hp)

Specifications

Engine
Max power (kW)110 kW
Compression ratio13
Engine power148 hp
Engine power150 PS
Capacity1997 cm3
Maximum torque210 N*m
Number of cylinders4
Valves per cylinder4
Turnover of maximum torque4000 RPM
Max power at RPM6000 RPM
Cylinder bore83.5 mm
Stroke cycle91.2 mm
Injection typedirect injection (direct)
Timing beltDOHC
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Engine modelMazda PE series (SkyActiv-G)
Boost typenone
Engine codePE-VPS
Bodywork
Front/rear axle load1030/1060 kg
Curb weight1525 kg
Front track1585 mm
Rear track1585 mm
Front track width1595 mm
Back track width1595 mm
Max trunk capacity1620 l
Height1680 mm
Width1840 mm
Ground clearance192 mm
Clearance192 mm
Full weight1985 kg
Wheel size225/65 R17
Wheelbase2700 mm
Trailer load (with brakes)3785 kg
Length4550 mm
Payload485 kg
Number of seater5
Min trunk capacity506 l
Body typeCrossover
Pitch Circle DiameterDIA67.1 5x114.3 mm
Gearbox and handling
Turning circle11.7 m
Number of gear6
Gearbox typeAutomatic
Drive wheelsFront wheel drive
Operating characteristics
Max speed189 km/h
Fuel tank capacity56 l
Highway driving fuel consumption per 100 km5.8 l
Mixed driving fuel consumption per 100 km6.9 l
City driving fuel consumption per 100 km8.8 l
Fuel95
Acceleration (0-100 km/h)9.9 s
Emission standardsEURO IV
Cruising rangefrom 640 to 970 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
