Mazda Axela 2003–2006

1 generation (BK))

General information

Number of doors4

Car classC

CountryJapan

Steering wheel positionRight

At a glance

Engine1498 cm3 Gasoline

Power113 hp

GearboxAutomatic

Origin

Japan

Series

Mazdaspeed hatchback 5-doors Sedan

Trim

1.5 AT (114 PS)1.5 MT (114 PS)2.0 4AT (150 PS)2.0 5AT (150 hp)2.0 AT 4WD (143 PS)2.3 AT (171 PS)2.3 MT (171 PS)

Specifications

Engine

Compression ratio10

Engine power113 hp

Engine power114 PS

Maximum torque140 N*m

Capacity1498 cm3

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4500 RPM

Max power at RPM6000 RPM

Cylinder bore78.0 mm

Stroke cycle78.4 mm

Max power (kW)84 kW

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Engine codeZY-VE

Engine modelZY-VE

Bodywork

Curb weight1210 kg

Ground clearance145 mm

Clearance145 mm

Height1466 mm

Rear track1515 mm

Back track width1515 mm

Front track1530 mm

Front track width1530 mm

Width1745 mm

Wheel size195/65 R15, 205/55 R16

Wheelbase2640 mm

Min trunk capacity413 l

Max trunk capacity413 l

Length4485 mm

Number of seater5

Pitch Circle DiameterDIA67.1 5x114.3 mm

Body typeSedan

Gearbox and handling

Turning circle10.4 m

Number of gear4

Gearbox typeAutomatic

Drive wheelsFront wheel drive

Operating characteristics

Acceleration (0-100 km/h)12.7 s

Max speed179 km/h

Fuel tank capacity55 l

Mixed driving fuel consumption per 100 km5.7 l

Fuel92

Suspension and brakes

Rear brakesdrum

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
