Audi 80 1986–1991

3 generation (8A/B3)
General information
Number of doors4
Car classD
CountryGermany
Steering wheel positionLeft
At a glance
Engine1588 cm3 Diesel
Power79 hp
GearboxManual
OriginGermany
Trim
1.6 AT (54 hp)1.6 AT (70 hp)1.6 AT (75 PS)1.6 D MT (54 hp) diesel1.6 MT (70 hp) gasoline1.6 MT (75 PS) gasoline1.6 TD AT (80 PS) diesel1.6 TD MT (80 PS) diesel1.8 AT (112 hp)1.8 AT (113 PS) gasoline1.8 AT (75 PS)1.8 AT (88 PS)1.8 AT (90 PS) gasoline1.8 E MT (112 hp) gasoline1.8 E MT (112 hp) gasoline, Four-wheel drive1.8 MT (113 PS) gasoline1.8 MT (75 PS) gasoline1.8 MT (88 hp) gasoline1.8 MT (90 PS) gasoline1.8 S MT (88 PS) gasoline1.9 AT (113 PS)1.9 AT (68 PS)1.9 D MT (68 PS) diesel1.9 MT (113 PS)2.0 AT (112 hp)2.0 AT (113 PS)2.0 AT (115 hp)2.0 AT (137 PS)2.0 AT (160 hp) gasoline2.0 E MT (113 hp) gasoline, Four-wheel drive2.0 E MT (113 PS) gasoline2.0 E MT (137 PS) gasoline2.0 E MT (138 hp) gasoline2.0 MT (112 hp) gasoline2.0 MT (112 hp) gasoline, Four-wheel drive2.0 MT (115 hp) gasoline, Four-wheel drive2.0 MT (160 hp) gasoline

Specifications

Engine
Maximum torque155 N*m
Capacity1588 cm3
Valves per cylinder2
Compression ratio23
Turnover of maximum torque2600 RPM
Number of cylinders4
Max power at RPM4500 RPM
Max power (kW)59 kW
Cylinder bore76.5 mm
Engine power79 hp
Engine power80 PS
Stroke cycle86.4 mm
Engine typeDiesel
Engine placementFront, longitudinal
Injection typeHPFP (Diesel)
Cylinder layoutinline
Timing beltOHC
Engine codeSB
Engine modelSB
Boost typeTurbocharged
Bodywork
Curb weight1056 kg
Clearance130 mm
Height1400 mm
Front track width1410 mm
Back track width1430 mm
Full weight1560 kg
Width1700 mm
Wheel size175/70 R14, 195/55 R15
Wheelbase2550 mm
Min trunk capacity373 l
Length4390 mm
Max trunk capacity453 l
Number of seater5
Pitch Circle DiameterDIA57.1 4x108 mm
Body typeSedan
Gearbox and handling
Number of gear5
Drive wheelsFront wheel drive
Gearbox typeManual
Operating characteristics
Acceleration (0-100 km/h)14.6 s
Max speed172 km/h
Highway driving fuel consumption per 100 km4.6 l
Mixed driving fuel consumption per 100 km5.3 l
City driving fuel consumption per 100 km6.5 l
Fuel tank capacity68 l
Fueldiesel
Suspension and brakes
Front brakesDisc
Rear brakesdrum
Front suspensionIndependent, spring
Back suspensionIndependent, spring

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
